Rescue equipment including monitors, breeching inlets, and specialized tools.
- info@blazebastion.com
- FLAT/RM A&B, 19/F, CKK Commercial Centre, No. 289 Hennessy Road, Wanchai, Hong Kong
Rescue Equipment
Rescue Equipment
Landing Valve & Breeching Inlet
| SPECIFICATION | |
| Body:Cast Iron | |
| Outlet:2*2.5”adaptor outlet +1*4”BSP pumper connection | |
| Outlet material :copper alloy | |
| Working Pressure:16bar | |
| Test Pressure:24 bar | |
| Upper Finishing:Red Electrostatic Powder Coating | |
| Lower Finishing:Black Bituminous Paint | |
| Dry barrel design eliminates damage to the hydrant caused by freezing or | |
| corrosion of the upper part. | |
| Breakway design to prevent accidents to the hydrants,where only the upper part | |
| of the flange will be broken upon impact. | |
| Externally sandblasted for smooth finish,painted red with electrostatic powder | |
| coating on the section above ground and double coated with black bituminous | |
| paint on the section below the ground. | |
| Barrel length extension kit in different lengths is available on request. | |
| XH-FF-01-05 | |
| XH-FF-01-06 | |
| 4”PN16 BS 4504 | |
| CODE NO. | |
| OUTLET | |
| INLET | |
| 2x(2-1/2”)male thread with cap and | |
| chain+1x4”BSP pumper connection | |
| 6”PN16 BS 4504 | |
| 2x21/2”Straight through Landing Valve | |
| with cap & chain+1x4”Pumper thread | |
| with cap and chain | |
| CODE NO. | |
| MATERIAL | |
| FINISHING | |
| XH-FF-08-01 | |
| STEEL | |
| RED POWDER COATING | |
| CODE NO. | |
| MATERIAL | |
| FINISHING | |
| XH-FF-08-02 | |
| STEEL | |
| RED POWDER COATING | |
| CODE NO. | |
| MATERIAL | |
| FINISHING | |
| XH-FF-08-03 | |
| STEEL | |
| RED POWDER COATING | |
| CODE NO. | |
| MATERIAL | |
| FINISHING | |
| XH-FF-08-04 | |
| STEEL | |
| RED POWDER COATING | |
| CODE NO. | |
| MATERIAL | |
| FINISHING | |
| XH-FF-08-05 | |
| COPPER ALLOY | |
| MATURAL | |
| CODE NO. | |
| MATERIAL | |
| FINISHING | |
| XH-FF-08-06 | |
| COPPER ALLOY | |
| MATURAL | |
| CODE NO. | |
| MATERIAL | |
| FINISHING | |
| XH-FF-08-07 | |
| ALUMINUM | |
| MATURAL | |
| MODEL | |
| MATERIAL | |
| FINISHING | |
| XH-FF-08-08 | |
| ALUMINUM | |
| MATURAL | |
| CODE NO. | |
| MATERIAL | |
| FINISHING | |
| XH-FF-08-09 | |
| ALUMINUM | |
| MATURAL | |
Monitor (Oscillating Type A)
| SPECIFICATION | |
| ADVANTAGES & VALUE | |
| 1. Being made of light and hard Aluminum for easy and simple handling a operation. | |
| 2. Various connectors available in different styles including Storz, NH, Russian, BS, JIC | |
| type, etc, for different markets. | |
| 3. Flow rate being controlled and adjusted easily by twisting 6-positions Slide Valve. | |
| 4. Specially designed for Foam spray besides fire fighting water spray. | |
| FIRE MULTI-PURPOSE NOZZLE | |
| GERMANY-STORZ | |
| AMERICAN-NH | |
| BRITISH-BS336 | |
| RUSSIAN-GOST | |
| JAPANESE-MACHINO | |
| FRENCH | |
| CODE NO. | |
| Connector Size | |
| Normal Flow Rate | |
| Maximum Flow Rate | |
| Working Pressure | |
| Net Weight | |
| Minimum Jet Distance | |
| XH-FF-03F-01 | |
| 1.5”/2”/2.5”/3” | |
| 150-660LPM | |
| 1000LPM | |
| 100PSI(7bar) | |
| 2.3KG | |
| 35M | |
| SPECIFICATION | |
| ADVANTAGES & VALUE | |
| 1.Attack nozzle with double fire-resist water curtains is newly designed for stronger and | |
| safer actual combat for fire-fighting with double fire-resist water curtains for the best | |
| self-protection besides the normal flow settings. | |
| 2.Various flow types and rates could be available easily by simply rotating the | |
| Stretching Tube, except that the middle water curtain could be turned on or off | |
| separately, various flow types are available including straight stream, double water | |
| -curtain, and straight stream together with water curtain. | |
| 3.The nozzle is made of strong non -corrosive aluminum alloy with third adjustment ball | |
| valve for simple and easy turn- on or off. | |
| 4.The production and logo are accepted to order! | |
| FIRE MULTI-PURPOSE NOZZLE | |
| CODE NO. | |
| Connector Size | |
| Normal Flow Rate | |
| Maximum Flow Rate | |
| Working Pressure | |
| Net Weight | |
| Minimum Jet Distance | |
| XH-FF-03F-02 | |
| 1.5”/2”/2.5” | |
| Selectable | |
| 700LPM | |
| 100PSI(7bar) | |
| 2.2KG | |
| 32M | |
Monitor (Oscillating Type B)
| SPECIFICATION | |
| ADVANTAGES & VALUE | |
| 1. Being made of light and hard Aluminum for easy and simple handling and operation. | |
| 2. Various connectors available in different styles including Storz, NH, Russian, BS, JIC | |
| type, etc, for different markets. | |
| 3. Flow rate being controlled and adjusted easily by twisting the Adjustable Ring at | |
| middle position of the nozzle and 3-position Slide Valve. | |
| 4. Specially designed for Foam spray besides fire fighting water spray. | |
| FIRE MULTI-PURPOSE NOZZLE | |
| CODE NO. | |
| Connector Size | |
| Normal Flow Rate | |
| Maximum Flow Rate | |
| Working Pressure | |
| Net Weight | |
| Minimum Jet Distance | |
| XH-FF-03F-04 | |
| 1.5"/2"/2.5"/3" | |
| 150-550LPM | |
| 700LPM | |
| 100PSI(7bar) | |
| 2.1KG | |
| 25M | |
| SPECIFICATION | |
| ADVANTAGES & VALUE | |
| 1. Being made of light and hard Aluminum for easy and simple handling and operation. | |
| 2. Various connectors available in different styles including Storz, NH, Russian, BS, JIC | |
| type, etc, for different markets. | |
| 3. Flow rate being controlled and adjusted easily by twisting the Adjustable Head in | |
| clockwise. | |
| 4. Specially designed for Foam spray besides fire fighting water spray. | |
| FIRE MULTI-PURPOSE NOZZLE | |
| GERMANY-STORZ | |
| AMERICAN-NH | |
| BRITISH-BS336 | |
| RUSSIAN-GOST | |
| JAPANESE-MACHINO | |
| FRENCH | |
| CODE NO. | |
| Connector Size | |
| Normal Flow Rate | |
| Maximum Flow Rate | |
| Working Pressure | |
| Net Weight | |
| Minimum Jet Distance | |
| XH-FF-03F-03 | |
| 1.5"/2"/2.5" | |
| 150-350LPM | |
| 500LPM | |
| 100PSI(7bar) | |
| 1.6KG | |
| 35M | |
